View Of The Front Panel - PULOX PO-200 Mode D'emploi

6. Installation

6.1 View of the front panel

6.2 Battery
Step 1. Refer to Figure 3 and insert the two AAA size batteries properly in
the right direction.
Step 2. Replace the cover.
Please take care when you insert the batteries for the improper
insertion may damage the device.
6.3 Mounting the Hanging Rope
Step 1. Put the end of the rope through
the hole.
Step 2. Put another end of the rope
through the first one and then tighten it.
7. Operating Guide
1) Insert the two batteries properly to the direction, and then replace the
cover.
2) Open the clip as shown in Figure 5.
Fig. 2 Front view
Fig. 3 Batteries installation
EN
