3-2-1. Jumper A & B
Figure 4. Jumper A & B
Pin Function
1
Terminal
Resistor
2
Table 3. SR-1600 PLUS jumper A & B status description
＊
Note：Jumper A pin1 & pin2 must be shorted and Jumper B pin1 & pin2 must
be shorted.
6
③⑧
Wiring
Short：
1. Signal shelf setting
Pin#1 and 2. Parallel connection setting at first and last shelf
Pin#2 (terminal shelf)
short/open Open：
Parallel connection：non-terminal shelf (Refer to
3-2-2.)
Status description
＊
Note
