3-1. Installation

3-2. Green Terminal Introduction

There are three green terminals at the rear side, please refer to
following figure：
Terminal
Jumper A & B
CN3 Dry contact and remote
Table 2. SR-1600 PLUS green terminal introduction
③⑧⑨
Description
Single shelf / Parallel connection setting
Remote setting, and dry contacts
① Insert SR-1600 shelf
in to the shelf plate.
② Fix SR-1600 shelf by
4 screws at its front side.
Note: Please make sure
the mounting bracket of
your rack mount deceive
is equipped before
installing SR-1600 shelf.
Figure 3.
SR-1600 PLUS shelf installation
5
