Troubleshooting

Problem
The motor does not operate or only operates in 1
direction.
The motor operates but the winch cable drum
does not turn.
The motor is weak or the winch cable drum turns
slowly.
The motor overheats.
8

Technical data

Nominal permitted winch cable load
Motor
Input voltage for maximum pulling power
Gear ratio
Dimensions
Winch cable drum dimensions
Winch cable dimensions
Weight
Maximum load
Winch cable speed
Motor current
Winch cable layer
Nominal load per layer
Winch cable length per layer
2022_001
The remote control is defective.
The electrical cables are damaged or have a bad
connection.
The motor is defective.
The clutch knob is in the disengaged position.
The battery charge level in the vehicle is too low.
There is bad connection at the battery terminals in
the vehicle.
The motor is defective.
The product has been operated for too long.
The motor is defective.
Technical data
Winch cable speed and motor current (first layer of winch cable)
0 kg 227 kg
3.2 m/min 2.8 m/min
10 A 25 A
Maximum load and winch cable length per layer
1 2
907 kg 740 kg
2.0 m 4.3 m
Cause
Speak to an authorized service center.
Do a check of the electrical cables and
connections. Clean the connections if it is
necessary.
Speak to an authorized service center.
Put the clutch knob in the engaged position.
Charge or replace the battery in the vehicle.
Clean the terminals on the battery. Remove
corrosion from the terminals.
Speak to an authorized service center.
Let the product become cool before you operate it
again. Do not operate the product continuously for
more than 1 minute at or near the nominal load.
Speak to an authorized service center.
907 kg
Permanent magnet, 0.7 kW
12 V (DC)
153:1
285 x 105 x 105 mm
Ø 31.5 x 73 mm
Ø 4 mm x 15 m
5 kg
454 kg
2.3 m/min
40 A
3 4
620 kg 540 kg
6.8 m 9.5 m
Action
680 kg 907 kg
1.8 m/min 1.0 m/min
60 A 90 A
5 6
470 kg 420 kg
12.5 m 15 m
