4. O
PERATION
This product is not designed for continual use. Make sure there are regular breaks during operation to maximize the life
of your laser. Always disconnect the Swarm 4 FX from power when not in use.
Control Panel

Operation

Menu Map

Mode
Auto Mode
Sound-Active Mode
Slave Mode
DMX
System Options
Page 18 of 80
To access the control panel functions, use the four buttons located underneath the display.
When the product is on, the LED monitor on the rear panel will show the current operating mode
(Standalone or DMX). The product will retain the last saved settings when powered off.
Button Function
<MENU> Selects an operation mode or backs out of the current menu option
<UP> Scrolls up the list of options or selects a higher value
<DOWN> Scrolls down the list of options or selects a lower value
<ENTER> Activates a menu option or a selected value
Programming Steps
Aut0
Aut1
Aut2
Aut3
Aut4
Aut-
Aut5
Aut6
Aut7
Aut8
Aut9
Sou-
SLA
–d511
Addr d001
LEdS
SYS
Description
Auto Mixed Effect
Moonflower - single color chase
Moonflower – multi-color chase
Laser + Strobe
Moonflower + Strobe
–S.99
S.01
Moonflower (single color chase) + Laser
Moonflower (multi-color chase) + Laser
Alternating color Laser
Laser
Strobe
Sou0 Sound Mixed Effect
Sou1
Moonflower - single color chase
Sou2 Moonflower – multi-color chase
Sou3 Laser + Strobe
Sou4 Moonflower + Strobe
Sou5 Moonflower (single color chase) + Laser
Sou6
Moonflower (multi-color chase) + Laser
Sou7
Alternating color Laser
Sou8 Laser
Sou9 Strobe
SLAV Slave mode
–d511
02CH
d001
Sets DMX address and personality
–d501
12CH
d001
on Turns LEDs on
oFF Turns LEDs off
tESt Test mode
rESt Reset to factory defaults
Swarm 4 FX User Manual Rev. 2
