Mount to 6 in. Housing without C-Clamps - Ordering # 53801102
1
Turning off the power
□
Make sure the power is turned off at
the source to the recessed can housing
where the fixture will be installed.
□
Remove the existing bulb and trim,
revealing the socket.
noTe: Stick the replacement label (F) on the
inner wall of the recessed can housing before
installation.
No C-Clamps
3
Connecting the socket
adapter
□
Screw the medium base (E26) socket
adapter (B) into the socket in the recessed
can housing.
B
2
Replacing the spring clips with
friction clips
□ Unscrew the two brackets holding the spring clips and
remove them.
□ Install two friction clips (C) onto the LED light module (A)
using the screws removed from the spring clip brackets.
C
4
Connecting the cables
□ Plug the cable connector on the socket
adapter (B) into the connector on the LED light
module (A).
B
6
Mount to 6 in. Housing without C-Clamps (continued)
5
Inserting the friction clips into
the recessed can housing
□ Insert one side of the downlight into the
recessed can housing and firmly push against
the friction clip (D), while inserting the other side
into the recessed can housing.
D
A
Mount to 4 in. Housing - ordering # 53801102
1
Turning off the power
□
Make sure the power is turned off at the source
to the recessed can housing where the fixture
will be installed.
□
Remove the existing bulb and trim, revealing
the socket.
noTe: Stick the replacement label (F) on the inner wall of the
recessed can housing before installation.
A
6
Pushing the LEd light module
into the recessed can housing
□ Carefully push the LED light module (A) into
the recessed can housing until the trim is flush
with the ceiling surface.
noTiCe: Select the preferred color temperature and
brightness before pushing the LED light module (A) into the
recessed can housing.
A
2
Connecting the socket adapter
□
Screw the medium base (E26) socket
adapter (B) into the socket in the recessed can
housing.
B
7
Please contact 1-855-384-7754 for further assistance.
