OPERATION

6. OPERATION
Hold the power head with your right hand on the rear handle and your left hand on the front handle. Keep a firm grip
with both hands while in operation. Power head should be held at a comfortable position with the rear handle about
hip height. Always operate power head at full throttle. If debris becomes wrapped around the attachment, RELEASE
THE SWITCH TRIGGER, and remove the debris.
WARNING
Contact with the trimmer cutting head while operating
can result in serious personal injury.
CUTTING TIPS See Figure 6.
Keep the trimmer tilted toward the area being cut; this is
the best cutting area.
„ The trimmer will cut better when moved from left
to right across the area to be cut; it is less effective
when moved from right to left.
„ Use the tip of the cutting line to do the cutting; do not
force cutting head into uncut grass.
„ Wire and picket fences cause extra cutting line wear,
even breakage. Stone and brick walls, curbs, and
wood may wear cutting line rapidly.
„ Avoid trees and shrubs. Tree bark, wood moldings,
siding, and fence posts can easily be damaged by
the cutting line.
„ Attach metal knob to the rubber hole on the rear
handle when in use, unlock the metal knob when not
in use.
ADVANCING CUTTING LINE
The trimmer is equipped with an Bump head. Bumping
the head to try to advance the line.
„ With the trimmer running, release the switch trigger.
„ Wait two seconds, and press the switch trigger.
NOTE: The cutting line will extend approximately 2mm
with each stop and start of the trigger until the cutting
line reaches the length of the grass deflector cut-off
blade.
„ Resume trimming
ADVANCING THE CUTTING LINE MANUALLY
„ Remove the battery pack.
„ Push the black button located on the cutting head
while pulling on cutting line to manually advance the
cutting line.
„ After extending new cutter line, always return the
machine to its normal operating position before
switching on.
LINE CUT-OFF BLADE See Figure 6.
„ This trimmer is equipped with a line cut-off blade on
the grass deflector. For best cutting, advance line
until it is trimmed to length by the line cut-off blade.
Advance line whenever you hear the engine running
faster than normal,or when trimming efficiency
diminishes. This will maintain best performance and
keep line long enough to advance properly.
WARNING
When servicing, use only identical replacement parts.
Use of any other parts may create a hazard or cause
product damage.
WARNING
To avoid serious personal injury, always remove the
battery pack from the tool when cleaning or
performing any maintenance.
GENERAL MAINTENANCE
Before each use, inspect the entire product for
damaged, missing, or loose parts such as screws, nuts,
bolts, caps, etc. Tighten securely all fasteners and caps
and do not operate this product until all missing or
damaged parts are replaced.
Avoid using solvents when cleaning plastic parts. Most
plastics are susceptible to damage from various types
of commercial solvents and may be damaged by their
use. Use clean clothes to remove dirt, dust, oil, grease,
etc.
WARNING
Do not at any time let brake fluids, gasoline,
petroleum-based products, penetrating oils, etc.,
come in contact with plastic parts. Chemicals can
damage, weaken, or destroy plastic which may result
in serious personal injury.
L
Only the parts shown on the parts list are intended to
be repaired or replaced by the customer. All other parts
should be replaced at an Authorised Service Centre.
WARNING
To avoid serious personal injury, always remove the
battery pack from the tool when cleaning or
performing any maintenance.
