5
EN

5. ASSEMBLY

ATTACHING GRASS DEFLECTOR See Figure 2.
WARNING
Avoid contact with the blade. Failure to avoid contact
can result in serious personal injury.
„ Remove the wing screw(17) from the grass deflector
„ Insert the tab(16) on the mounting bracket in the
slot(15 ) on the grass deflector
„ Tighten the screw(17)securely.
WARNING
Do not allow familiarity with products to make you
careless. Remember that a careless fraction of a
second is sufficient to inflict serious injury.
WARNING
Always wear eye protection. Failure to do so could
result in objects being thrown into your eyes resulting
in possible serious injury.
WARNING
Do not use any attachments or accessories not
recommended by the manufacturer of this product.
The use of attachments or accessories not
recommended can result in serious personal injury.
INSTALLING AN ATTACHMENT TO THE POWER
HAED See Figure 3
„ Loosen the knob(19) on the coupler(10) and remove
the hanger cap from the attachment(18).
„ Push in the button located on the attachment(18)
shaft. Align the button with the guide recess on
the power head coupler(10) and slide two shafts
together. Rotate the attachment shaft until the button
locks into the positioning hole.
„ Tighten the knob(19) securely.
ATTACHING THE FRONT HANDLE See Figure 4.
„ Install the main handle(21) onto the shaft, place the
bar(20) on the top of main handle(21),making sure
the bar(20)is pointing left while holding unit.
„ Place the clam(23) on the back side of the main
handle(21) onto shaft.
„ Take 2 bolts provided and secure the bolts to clamp
with Philips screw driver(not provided).
TO INSTALL BATTERY PACK See Figure 5.
„ Place the battery pack in the trimmer. Align raised
ribs on battery pack with grooves in the trimmer's
battery port.
„ Make sure the latch on bottom of the battery pack
snaps in place and that battery pack is fully seated
and secure in the trimmer before beginning operation.
STARTING/STOPPING THE TRIMMER
To start the power head:
„ Press the power button(6)
„ Depress the lock-out button(4)and squeeze the
switch trigger(7)
„ Press high speed button (5)to increase speed
depending upon grass condition.
To stop the power head:
„ Release the switch trigger(7)
„ The unit will power itself down after being idle for 1
minute.
WARNING
Noise. A degree of noise from the machine is not
avoidable. Route noisy work is to be licensed and
limits for certain periods. Keep rest periods and they
may need to restrict the working hours to a minimum.
For their personal protection and protection of people
working nearby, an appropriate hearing protection
shall be worn;
Vibration. Always wear safety and anti-vibration glove.
Excessive vibration may cause white finger disease
or carpal tunnel syndrome. If you notice an
unpleasant sensation or skin discoloration during use
of the machine on your hands once you stop working.
Place an adequate work breaks.. And continual and
regular users should monitor closely the condition of
their hands fingers
ASSEMBLY
