VHO200

Cleaning the containers

Before proceeding with these operations, turn off the
vacuum cleaner and remove the plug from the power
socket.

Chip basket

■ Clean the container after each emptying (see "Emptying
the chip basket" paragraph).
■ Check that the holes are free of dirt; clean them if
necessary.

Liquid container

1 Float support
2
Chip basket
3 Container clamp
4 Liquid discharge valve
■ Empty the liquid container (see "Emptying the containers"
paragraph).
■ Open the liquid container clamp (3).
■ Lift the motor head.
■ Remove the float and its support (1) or the chip basket
(2).
■ Wash the container with water to remove deposits.
■ Open the discharge valve (4) to empty the container.
■ After emptying it, close the discharge valve (4).
■ Place the float and its support or the chip basket (if
applicable) back into position.
Note: Check that the float holder is properly aligned.
■ Lock the motor head by using the liquid container clamp
(3).
Close the lever on the clamp with care to avoid
trapping your hands between the lever and the
band. Use gloves that provide ANSI/ISEA level "2"
protection.
US
01/2014
WARNING!
Figure 10
WARNING!
Cleaning or replacement of the safety
filters
1 Filter
2 Filter box
■ Lift the motor head.
■ Remove the filter box (2) by unscrewing the three knobs.
■ Remove the filter (1) and clean it with water or replace it
if necessary.
■ Reinstall the filter (1) making sure it is correctly
positioned.
■ Install the filter box and secure it by replacing the three
knobs.
■ Lower the motor head and secure it to the container with
the clamp.

Using the chip basket filter (optional)

1
Chip basket filter
2 Basket kit
When vacuuming sludge (slush or other residual materials
which is not trapped by the basket kit), it is necessary to use
the chip basket filter.
Install the filter (1) inside the basket (2) by matching the
orientation shown.
Periodically check the filter condition and, if necessary,
replace it.

Tightness inspection

1 Vacuum hose
2
Liquid level indicator tube
■ Hoses check
Make sure that the suction connecting hose (1) and the
level hose (2) are in a good condition and correctly fixed.
If the hose is damaged, broken or can not be properly
connected to the unions, it must be replaced.
1 Gasket
2 Liquid container
3
Motor head
■ Motor head tightness check
Replace the seal (1) between the container (2) and the
motor head (3) if it is torn, cut, etc.
10
Figure 11
Figure 12
[ NOTE ]
Figure 13
Figure 14
