The illustration shows the harnessing points and lifting procedure.
UN41 0777NQ
Unpacking and assembly
The assembly of the work vehicle must be carried out
at an authorised service centre or at company facilities
equipped with appropriate equipment and suitably
trained personnel, in order to guarantee safety during
unpacking and installation.
During unpacking, check that the components are in
The illustration shows a basic assembly diagram of the WOLF PRO work vehicle assembly.
8
5
UN41 0778NQ
English language
INFORMATION CONCERNING HANDLING AND INSTALLATION
3
7
good condition and tally with the number stated; in the
event of damage, report the damage to the retailer or
directly to the manufacturer within 8 days of receiving
the machine.
The packing materials must be appropriately disposed
of or recycled in accordance with the laws in force.
4
6
12
4
WOLF PRO/1
WOLF PRO/2
WOLF PRO/3
WOLF PRO/4
WOLF PRO/5
1
WOLF PRO/6
2
