SAFETY MESSAGE TO INSTALLERS
FEDERAL SIGNAL LIGHT SYSTEMS
People's lives depend on your safe instal-
lation of our products. It is important to
read, understand and follow all instructions
shipped with the products. In addition, listed
below are some other important safety in-
structions and precautions you should follow:
•
To properly install a light assembly: you
must have a good understanding of auto-
motive electrical procedures and systems,
along with proficiency in the installation
and use of safety warning equipment.
•
When drilling into a vehicle structure,
be sure that both sides of the surface are
clear of anything that could be damaged.
•
A light system is a high current device. In
order for it to function properly, a sepa-
rate ground connection must be made. If
practical, it should be connected to the
negative battery terminal. At a minimum,
it may be attached to a solid metal body
or chassis part that will provide an ef-
fective ground path as long as the light
system is to be used.
•
Locate light system controls so the VE-
HICLE and CONTROLS can be operated
safely under all driving conditions.
•
This product contains high intensity LED
devices. To prevent permanent eye dam-
age, DO NOT stare into the light beam at
close range.
•
You should frequently inspect the light
system to ensure that it is operating
properly and that it is securely attached
to the vehicle.
•
File these instructions in a safe place and
refer to them when maintaining and/or
re-installing the product.
Failure to follow all safety precautions and
instructions may result in property damage, serious
injury, or death to you or others.
I.
GENERAL.
This instruction sheet provides directions for instal-
lation, and maintenance of the EMS Escape lightbar. The
EMS Escape lightbar is designed to mount on the vertical
surface of vehicles. Typical applications would include am-
bulance, fire, and rescue bodies. The EMS Escape lightbar
INSTALLATION AND MAINTENANCE INSTRUCTIONS
EMS ESCAPE™ LIGHT BARS
OF
FOR
may be mounted direct or via the Quick Track™ mounting
system to the vehicle's surface.
II.
UNPACKING.
After unpacking the light bar, inspect it for damage
that may have occurred in transit. If the unit has been
damaged, file a claim immediately with the carrier, stating
the extent of damage. Carefully check all envelopes, ship-
ping labels and tags before removing or destroying them.
Ensure that all parts listed in the Kit Contents List are
included in the package.
Kit Contents List
Qty.
Description
4
3/8-16 x 2", Carriage Bolt, S.S.
8
M8 x 25mm, Set Screw w/Nylok, S.S. 7008039A
4
3/8 Flat Washer, S.S.
4
3/8 Lockwasher, S.S.
4
3/8-16 Hex Nut, S.S.
2
Mounting Strip Gasket (10')
1
Grommet, Seal
2
Carriage, Seal
III. INSTALLATION.
The EMS Escape light bar is completely wired at the
factory and does not require any additional internal wir-
ing. All the conductors necessary for control of any and all
basic and optional functions are contained in the supplied
cable(s). Installation of options will require additional wir-
ing in the light bar.
The basic light functions of the unit must be controlled
by a user-supplied control head.
Light system controls must be located so that
VEHICLE and CONTROLS can be operated
safely under all driving conditions.
When installing equipment inside air bag
equipped vehicles, the installer MUST ensure
that the equipment is installed ONLY in areas
recommended by the vehicle manufacturer.
Failure to observe this warning will reduce
the effectiveness of the air bag, damage the
air bag, or potentially damage or dislodge the
equipment, causing serious injury or death to
you or others.
The EMS Escape lightbar is designed for mounting di-
rectly to the vehicle's surface or via the Quick Track mount-
ing system. The direct mounting method incorporates
carriage bolts, washers, lockwashers, and nuts to provide a
secure and somewhat permanent installation, unless provi-
sions for future removal are made during the assembly of
your vehicle.
-1-
Part No.
7004A024-32
7072A035
7074A046
7059A063
8003006A
8003127A
8003128A
