UL Prescriptions
WARNING: Risk of Electric Shock, wait No. 3 minutes before operating.
Only for drive with mark:
Use with suitable copper (CU) conductor only.
Maximum surrounding air temperature 0-40°C up to 55°C with a linear de-rating with In (at 55°C) 50% of In (at 40°C).
To be installed in a compartment able to maintain: Pollution Degree 2.
Overvoltage Category: 3 for power board, 2 for logic and control boards.
suitable for use on a circuit capable of delivering not more than 5000 Arms symmetrical amperes, 240 Vac
maximum.
Use fuse only.
Integral solid state short circuit protection does not provide branch circuit protection. Branch circuit protection fuses
as indicated in this description shall be present in the end-use application as indicated in the installation manual.
EXTERNAL (RECOMMENDED) SEMICONDUCTOR PROTECTION FUSES
Recognized Semiconductor Fuses (JFHR2,JFHR8).
See table below for the manufacturers, model number and electrical ratings of the Fuses analyzed and/or tested.
SIBA GMBH 50 179 06 200 kAac A.I.C.
SIBA GMBH 50 199 06 30 kAac A.I.C.
SIEMENS AG 3NC1016 200 kA
3 fuses for 3 phase AC-INPUT
2 fuses for 2 phase AC-INPUT
1 fuse for 1 phase AC-INPUT (Only for Line, not for Neutral connection.)
The Motor Drive of "miniECO" series may be protected by any equivalent UL Listed (JDDZ, JDDZ7) or UL
Recognized External Semiconductor Fuses (JFHR2, JFHR8), on condition that these fuses have the same ratings
of the above fuses evaluated during the Short Circuit Test and in particular with I
the tested fuses.
Values of the Field Wiring Tightening Torque:
M1 Note: PHOENIX CONTACT:
M1 Note: DINKLE:
M2 Note: PHOENIX CONTACT:
M2 Note: DINKLE:
CN1 Note: PHOENIX CONTACT:
CN1 Note: DINKLE:
CN2 Note: PHOENIX CONTACT:
CN9 Note: PHOENIX CONTACT:
CN9 Note: DINKLE:
Motor Overload Protection is provided connecting R/C (XGPU2,XGPU8) sensing PTC/s, which supplied at 24Vdc
has/have a resistance higher than 5K" at the maximum value permitted by the insulation system of the motor
commanded. PTC/s shall be connected to terminal block CN4 at pin 24, 26.
The motor out field wiring cable are able to be up to max 20AWG.
Symm. A.I.C.
RMS
20 - 12 AWG, Cu, 5-7 lb in.
20 - 12 AWG, Cu, 4.5 lb in.
20 - 12 AWG, Cu, 5-7 ld in.
20 - 12 AWG, Cu, 4.5 lb in.
30 - 14 AWG, Cu, 2-4 ld in.
30 - 14 AWG, Cu, 1,7 ld in.
30 - 14 AWG, Cu, 2-4 ld in.
30 - 14 AWG, Cu, 2-4 ld in.
30 - 14 AWG, Cu, 1,7 ld in.
2
16A
156A
sec
2
16A
320A
sec
2
16A
150A
sec
2
t and Ipeak equal or lower than
ESA elettronica S.p.A.
Unità Locale di Bentivoglio
Via Monari Sardè, 3
40010 Bentivoglio (BO) ITALY
Tel. ++39.0516640464
Fax ++39.0516640784
Web:
www.esa-automation.com
E-mail:
customer.care@esa-automation.com
500 A
700Vac
500 A
1000Vac
500 A
600Vac
