LoRaWAN SENSORS- Mode d'emploi / User guide version V2.0
2.5. Configuring the LoRaWAN SENSORS unit (digital input)
In this configuration, the device send a data frame only when a state is changing on at least one dry contact input
.
our LoRaWAN SENSORS is configured via the combination of switches. The following settings can be changed:
•
Transmission interval
•
Inputs activation (sensors 1 and 2)
•
The type of sensor connected
If only one of two ways is configured in dry contact, both inputs will work in dry contact
CONFIGURATION TABLE:
Parameter
Debounce Time
(Only available
on Digital Input Mode)
Activation of sensor inputs
Sensor Type
PLEASE NOTE: You must set your switches before activating the meters. Once at least one way is activated and the LoRaWAN SENSORS has
been started via magnet, the configuration with the switchs can no longer be possible.
If the configuration has any difference between the switchs and the product register value, the consistency error bit will be set to on in the
frame. This consistency verification is carried out every minute.
2.6. Closing the casing
Once stages 2.2, 2.3 and 2.4 have been carried out, you can close the casing of the LoRaWAN Sensors unit.
Procedure:
•
Make sure that the seal is properly positioned on the base
Value
100ms
1s
10s
1mn
Sensors 1&2 inactives
Sensor 1 active
Sensor 2 active
Sensor 1&2 actives
Sensors 1&2 Dry Contact
SW3
SW1
SW2
(Sensor 1)
OFF
OFF
OFF
ON
ON
OFF
ON
ON
OFF
ON
OFF
ON
Seal
SW4
SW5
(Sensor 2)
(Sensor 1)
(Sensor 2)
OFF
OFF
ON
ON
ON
Page
GB
SW6
ON
36
of 45
