Connect the fixture wires to the wires in the junction box.
Twist the wires together and secure with wire connectors.
Recommended Grounding Method
Use a green ground "pigtail" (not provided) and twist
one end together with the bare fixture wire and the box
ground wire. Secure with a wire connector. Secure the
other end of the "pigtail" with the GND screw on the
mounting plate.
If you have metal junction box, you may not need the green
"pigtail". If you are unsure about the grounding method,
consult your local building code.
White to white
Black to black
4
209879-02
