3.2 Location

VacuSafe is intended for use in a laboratory environment.
The instruments may not be located:
Near a source of UV-radiation
●
In a place susceptible to water spray or where con-
●
tact with chemicals is possible.
In a place where explosion potential is present.
●
The proper location:
Has a stable, flat base
●
Has adequate space for fitting a second bottle for
●
combined mode aspirate/dispense and for a foot
switch.
is ventilated sufficiently
●

3.3 Connecting to power supply

Checking the voltage
Check the local voltage; it must be compatible with the
voltage indicated on VacuSafe.
The instrument voltage is indicated on the rear panel of
VacuSafe.
Warning: Connecting to the wrong voltage may
damage electrical components of VacuSafe.
Connection to power supply
Connect VacuSafe to the power supply using the power
cable provided.

3.4 Connecting the foot switch

Using the foot switch, one can switch between the
"aspirate" and "dispense" modes. It is available as an
optional accessory. The foot switch cable should be
connected to the socket labelled FOOT SWITCH at the rear
of VacuSafe.
