Door Alignment; Energy Saver Mode And Normal Operating Sounds - Kitchenaid Krfc704Fbs Guide D'utilisation

Door Alignment

Tools Required
Depending on the width of the door opening, the following tools
may be required to remove, replace, and align the refrigerator
doors.
Tools Needed:
1/4" hex nut driver – base grille, freezer drawer screws, and
■
brake/leveling feet
Tools Provided:
1/8" hex key – handle setscrews and door alignment
■
Door alignment tool instructions
Features:
Creates an even horizontal gap
■
between the refrigerator doors.
Solves door alignment issues during
■
installation and improves door seal.
Align Refrigerator Doors
✔ If doors are uneven:
Ensure the refrigerator is level.
❏
Keeping both refrigerator doors closed, pull out the freezer
❏
drawer. Locate the bottom hinge pin of the right-hand
refrigerator door. The alignment screw is inside the bottom
hinge pin.
Insert the short end of the 1/8" (3.2 mm) hex key wrench
❏
(packed with the Door Handle Installation Instructions) into
the bottom hinge pin until it is fully engaged in the alignment
screw.
To raise the refrigerator door, turn the hex key to the right.
❏
To lower the door, turn the hex key to the left.
❏
Continue to turn the alignment screw until the tops of the
❏
doors are aligned.
A. Bottom hinge pin
B. 1/8" (3.2 mm) hex key wrench
A
B
Shelf Height Adjustment
Shelf height can be adjusted by changing the adjustable shelf
mounts between their vertical and horizontal positions.
Carefully lift the shelf off the shelf mounts and turn the flipper
■
to the desired orientation.
Repeat for remaining shelf mounts.
■
Ensure the shelf is properly seated on the shelf mounts.
■
Energy Saver Mode And Normal
Operating Sounds
Your new French Door bottom-mount refrigerator has been
designed to optimize energy efficiency and better regulate
temperatures to match cooling demand.
You may notice that it operates differently from your previously
owned refrigerator.
It is normal for the high-efficiency compressor to run for extended
periods of time at varying speeds in order to consume only the
energy necessary for optimum efficiency.
In addition, during various stages of the cooling cycle, you may
hear normal operating sounds that are unfamiliar to you.
Energy Saver Mode
Turns off the anti-sweat heaters to save the customer power.
When the icon is lit, the function is activated (heaters off); icon
off means that it is inactive (heaters on). The user can toggle the
feature by pressing the button. If the user lives in a climate with
high humidity, Energy Saver mode is not recommended.
7
