battery to short-circuit, resulting in da-
mage, burns or even the danger of fire.
• Remove batteries from the device if this
is not going to be used for a prolonged
period, unless it is to be used in emer-
gencies!
• NEVER touch batteries which have
leaked without appropriate protection.
If the leaked liquid comes into contact
with the skin, you should rinse off this
area of the skin immediately under run-
ning water. Make sure at all events that
your eyes and mouth do not come into
contact with the liquid. If they do, seek
medical advice immediately.
• Clean the battery contacts and the
equivalent contacts in the device before
inserting the batteries.

Assembly

The bench drill is supplied disassembled.
Clean the column tube (6), baseplate (9),
drilling bench (12), vice (13) and the drill
chuck (21) beforehand, with a dry cloth.
1. Place the column tube (6) on the base-
plate (9).
The red marking at the base of the
column tube (6) and the recess in the
baseplate (9) must line up.
Bolt the column tube (6) to the baseplate
(9) with the three assembly srews (8) (size
13 mm) supplied. Tighten the assembly
srews (8) moderately tight so that the th-
reads in the baseplate (9) do not strip.
2. Place the drilling bench (12) on the
column tube (6). Push the drilling bench
(12) into a lower position. Use the
locking handle (7) to fix the drilling
bench (12) in a lower position.
3. Place the vice (13) on the drilling
B
bench (12). Screw it firmly onto
the drilling bench (12) by means
of the enclosed assembly screws
(11) (size 17 mm) together with
the washer and the lock washer
in the order as shown.
The two assembly screws (11)
should be positioned diagonally
opposite each other.
4. Place the motor unit (5) on the
C
column tube (6). Secure the motor
unit (5) with the two clamping
screws (16) on the side using the
enclosed Allen key (32).
5. Bolt the three drill lifting arms
(22) into the spindle guide (25).
Tighten the three hole lifting
arms with a spanner (Width ac-
ross flats 6).
6. Release the clamping screw from
the depth stop (30).
7. Mount the laser on the motor unit
(5) using the fixing screw (34).
Make sure that the battery com-
partment (
of the hand spindle guide (
25).
8. Put the safety device (23) on the
upper part of the drill spindle
(20).
9. Secure the safety device (23)
with the clamping screw (19).
10. Fold the safety device (23) up-
wards. Insert the chuck (21) on
the taper of the drill spindle (20).
Push the drill chuck (21) onto the
drill chuck tip with a few light
taps. Use a plastic hammer for
this purpose.
