SET TIMER
The following procedure must be followed to turn on the air conditioner at the desired time (the remote
control and the air conditioner are turned off):
1. Press the Timer button.
2. Choose the desired mode by pressing the Mode button.
Choose the desired temperature by pressing the gh button (only possible if the 'cool' or 'heat' mode
3.
is selected).
4. Choose the fan speed (low, medium or high) or the automatic mode
(only possible if the Feel, Cool or Heat mode is selected) by pressing the
Fan button
In the Dry mode the fan always runs on the Auto mode.
5. Choose Swing or No swing by pressing the Swing button.
6. Press the Timer button ('h' flashes).
Use the gh button to select the period the air conditioner has to be
7.
turned on (between 0 and 10 you can set the time per half hour; bet-
ween 10 and 24, you can set the time per hour).
8. Press the Timer button ('h" will stop flashing) and the set time will
appear on the display.
9. Press on the Timer button again to delete de selected data from the
memory.
Note: When no buttons have been pushed during setting the timer function, the remote control will
automatically turn off after 10 seconds.
The following procedure must be followed to turn off the air conditioner at the desired time (the remote
control and the air conditioner are turned off):
1. Press the Timer button.
2. Use the gh button to select the period the air conditioner has to be turned off (between 0 and 10 you
can set the time per half hour; between 10 and 24, you can set the time per hour).
3. Press the Timer button ('h" will stop flashing) and the set time will appear on the display.
4. Press on the Timer button again to delete de selected data from the memory.
Note: When no buttons have been pushed during setting the timer function, the remote control will
automatically turn off after 10 seconds.
Note: if 'h' is flashing and you press the ON/OFF/RUN button once, the set temperature will appear on
the display. You can now change the temperature with the gh button. If you press the Timer button,
the time will appear again and can be changed at this moment*. If you press the Timer button again,
all data will be saved and the remaining time (the air conditioner will be turned on) will appear on the
display.
* When you press the ON/OFF/RUN button in stead of the Timer button, the remote control will be turned off.
Press the Timer function to check the settings on the display.
4
48
SWING function
Carry out the operations below when the air conditioner is in service.
1. Press the SWING button to activate the swing function. The vertical blades will now move up and down
to distribute the air to the room better in the vertical direction.
2. Press the SWING button again, the vertical blade will stop at the position during the moment the
SWING button is pressed.
Horizontal air distribution
The horizontal air flow can be changed manually by adapting the horizontal blades with the levers, see
picture.
Levers
SLEEP mode
Carry out the operations below when the air conditioner is in service.
1. Press the SLEEP button to activate the sleep function.
2. Press the SLEEP button or the MODE button to select another mode and turn off the SLEEP mode.
In SLEEP mode the air conditioner will control the room temperature as follows:
1. In the cooling mode the set temperature will be increased automatically by 1°C after 1 hour. After two
hours, the set temperature will be increased again by 1°C.
2. In the heating mode the set temperature will be decreased automatically by 1°C after 1 hour. After two
hours, the set temperature will be decreased again by 1°C.
3. In the FEEL mode the air conditioner will set the temperature according point 1 or 2, depending on
whether the air conditioner must cool or heat the room.
In the SLEEP mode, the air conditioner will be turned off automatically after 10 hours.
The SLEEP mode can only be used when the FEEL, cooling or heating modus is selected.
