When calling up a track route the magnetically op-
erated articles are activated in the sequence of
their inputs i.e. their position numbers.
If there is doubt while running the layout follow-
ing a break in the programming or operation when
Track route programming
Intended action Key sequence Display
e.g. for Route 23 0
2 + 3
Call-up Editor press Key "resc"
for 5 sec.
Input of Contents:
i.e. set turnout 4 4
input to divergent esc
s
i.e. set turnout 5 5
input to straight ok
s
i.e. set turnout 123 1 + 2 + 3
input to divergent esc
s
Store the track ok
route
Yes, acknowledge ok
If an input error of the turnout number or position is
noticed before pressing the key "..." for the follow-
ing position it is possible to overwrite this position
immediately: if for instance the input for turnout 123
was incorrect and should have been 124, simply put
in 124 and again press the "divergent/esc" key and
then press the cursor key "s" to get to position
P.04.
If however all inputs made for the track route should
be disregarded, i.e. not store the inputs and discon-
tinue, press the key "esc" after the indication "P.04"
and "End". The display shows "dEL" which is the
question wether to erase this track route: in this case
confronted with a three-digit number indication in
the display if one is in layout- or editing mode help
is available by pressing one of the cursor keys: if the
position indication "P..." appears in the display it is a
confirmation that the editing mode is still active.
F. ..
F.23
Edt
P.01
End
004
004 (+red LED illuminated)
P.02
End
005
005 (+green LED illuminated)
P.03
End
123
123 (+red LED illuminated)
P.04
End
Sto
F.23
you answer the question with "yes" by pressing the
key "ok". The display will now show again "F.23".
To change the program of a track route it is
first called up as above and the editor is activated.
With the cursor "up" and "down" every position of
a defined track route can be reached. The content
of each position can be written over the same as
when programming. A particular position can also
be erased by writing 000 over the contents. Positions
can also be inserted by following the same proce-
dure. Storing of a reprogrammed track route can be
done after the position indication "End" by pressing
of the "ok" key twice.
Remarks
editor for track 23 is activ
Position 1 has end marking
= track route is empty
turnout 4 divergent
acknowledged
turnout 5 straight
acknowledged
turnout 123 divergent
acknowledged – three posi-
tions are occupied!
Store contents?
stored!
