Functional Description and Specifications

Disconnect battery pack from tool or place the switch in the locked or off
W RNING
position before making any assembly, adjustments or changing
accessories. Such preventive safety measures reduce the risk of starting the tool accidentally.
FIG. 1
DEPTH G UGE
RELE SE BUTTON
LOCKING
SLEEVE
DUST
SHIELD
DEPTH
G UGE
UXILI RY
H NDLE
Model Number
Voltage rating
Shank style
Please refer to the Charger Manual included with your tool.
NOTE: For tool specifications refer to the nameplate on your tool.
Cordless Hammer Drill
VENTIL TION
OPENINGS
SELECTOR DI L
RELE SE BUTTON
WORK LIGHT
B TTERY P CK
RELE SE BUTTON
BUTTON FOR
B TTERY CH RGE
CONDITION
RH328VC-36
36 V
®
SDS-plus
Battery Packs/Chargers
-
VIBR TION
D MPER
Maximum Capacities:
Material
Concrete
Steel
Wood
7-
FORW RD/REVERSING
LEVER ND TRIGGER LOCK
RUBBERIZED
GRIP
V RI BLE SPEED
CONTROLLED
TRIGGER
SELECTOR DI L
B TTERY P CK
TEMPER TURE
INDIC TOR
LIGHT
B TTERY
CH RGE
CONDITION
LIGHT
1-1/8"
1/2"
1-1/4"
