Technical Information; Notes On The Radio System - SPORTSTECH CX2 Manuel

Technical Specifications of the Device
Model
Size unfolded
Size folded
Net weight
Max. user weight
Power supply
Generated electricity
Generated tension
Power
Weight of the flywheel
Drive system
Resistance Levels
Braking system
Min. speed
Max. speed
Noise emission
Ambient temperature (installation site)
The device has the following radio transmission system:
2,4 GHz 7mA Bluetooth
Frequency band: 5 KHz - 5,3 KHz
Maximum transmit power radiated: 15mW

TECHNICAL INFORMATION

NOTES ON THE RADIO SYSTEM

25
CX2
1240 x 620 x 1340 mm
550 x 620 x 1340 mm
30 kg
120 kg
DC generator (self-sufficient)
0,5 A
5 V
2,5 W
27 kg
Grooved belt drive
24
Magnetic brake system
1,0 km/h
10,0 km/h
< 68 dB
-10°C - 40°C
EN
