2 Connecting and display elements
8
7
1
Control: operating voltage
connection and I/O coupling
2
Valve: valve connection
3
Display
4
Operating buttons
16
1 2 3
6
5
Type plate
6
Groove for identification
signs (type IBS 6x10)
7
Measuring system
connection
8
Earth/ground connection
