2. TECHNICAL SPECIFICATIONS (continued)

2.3 Dimensions

Model(s): HP3005AT1RM
Unit : mm
Model
Mark
A
B
C
D
E
F
G
H
6
B
F
HP3005AT1RM
545
805
265
300
270
550
93
270
Water outlet
diam. 50 mm
Water inlet
diam. 50 mm
C
D
