4) REC AUDIO
Select if you want to enable audio recording for the selected channel (ON / OFF).
Note: This function is available only when your connected device supports audio recording.
5) CHANNEL TITLE
Click "EDIT" to input the channel title (up to six characters). The default title is the channel number.
6) PORT FORWARD / PORT FORWARD ENABLE
These two functions are used when you only want to see a single channel of this NVR remotely.
a) Set the port number for the channel in "PORT FORWARD". The default value for CH1 is 81, and the
default value for CH2 is 82... etc. If you want to change the port number to other value, the range is from
1 ~ 65535.
b) Select "ON" in "PORT FORWARD ENABLE".
c) The address of the channel will be "http://
Explorer, and see if you can access the device connected channel individually.
Note: The user name and password are still required to access the device connected to the channel.
Make sure you know the user name and password to access the device. For details, please refer
to its user manual.

6.4.3 DETECTION

CONNECTION CH1
CAMERA ALARM
DETECTION SENSITIVITY
ALERT MOTION
NETWORK
AREA
DISPLAY
INTERNAL ALARM
RECORD
NOTIFY
EXIT
1) ALARM
Select N.C./ N.O depending on your installation need. The default alarm value is OFF.
2) SENSITIVITY
Select the detection sensitivity of the selected channel, the lower the value, the higher the sensitivity.
3) MOTION
Select if you want to activate the motion detection function for the selected channel (ON/OFF).
4) AREA
Click "EDIT" to set the motion detection area.
There are 16 × 12 grids per camera for all channels. Pink blocks represent the area that is not being detected
while the transparent blocks are the area under detection.
Note: To exit area setting and return to the detection page, right click your mouse.
5) INTERNAL ALARM
This function appears only when the camera connected supports human detection.
Select "ON" to enable human detection, or "OFF" to disable it.
ADVANCED CONFIG
CH2 CH3 CH4 CH5
(For selected camera models only)
:
NVR_address port_number
CH6
OFF
0
ON
EDIT
ON
29
". Enter the address in Internet
