STEP 11
REQUIRED TOOL: 1/2" WRENCH
With the Hat Brackets [P] from STEP 5 & 6 still loosely secured, position the carrier along the Slide Tubes [M] to adjust for
required vehicle clearances (user discretion). Once the final clearance adjustments are made, verify Slide Tubes are slid
all the way against the Rubber Bummers [L] and fully secure all Hat Brackets [P] and hardware from Steps 5 & 6.
NOTE: Users wanting less clearance between the tow vehicle and carrier should position the Hat Brackets [P] closer to
the vehicle on the Slide Tubes [M] [Figure 16].
NOTE: Users wanting more clearance between the tow vehicle and carrier should position the Hat Brackets [P] further
away from the vehicle on the Slide Tubes [M] [Figure 17].
IMPORTANT: The Hat Brackets [P] must be positioned forward of the Handle Silent Hitch Pin [D] location. Be sure to
allow room for the Silent Hitch Pin with Handle to turn and operate as required.
DO NOT ALLOW HAT BRACKETS [P] TO OVERLAP THE 3.5" WARNING LABEL LOCATED
ON ON THE SLIDE TUBE. Failure to do so will permit over-extension of the safety cable allowing
MIN INSTALLED CLEARANCE
D
M
P
[Fg. 16]
REQUIRED TOOL: 7MM WRENCH & PHILLIPS HEAD SCREW DRIVER, TWO (2) 7/16
STEP 12
WRENCH OR SOCKET (OPTIONAL)
Mount each LED Light onto a LED Mount
Bracket [UU] with supplied hardware in
the order shown. [Fg. 18]
OPTIONAL: Optional License Plate
Brackets [TT] may also be included in-
between supplied hardware on one LED
Light only, as shown for the mounting of a
vehicle license plate. [Fg. 21]
the capsule to slide off and cause damage or personal injury.
WARNING
[Fg. 18]
