Let's Go Aero GearDeck H00604 Manuel Du Produit page 3

STEP 3
Rub all four sides of the TwinTube [A] Spine with Wax Block
[K]. [Fg. 6 & 8]
STEP 4
Insert the female Slide Tubes [M] all the way onto the fixed
tubes of the TwinTube [A] Spine. [Fg. 7]
Be sure that the mounting holes on the TwinTube [A] and
Slide Tubes [M] align and that the small hole at the end of
the tub is facing down.
STEP 5
REQUIRED TOOL: 1/2" WRENCH
Set the one (1) Wing Track [N] on top of the Slide Tubes [M].
Place two (2) Hat Brackets [P] underneath the Slide Tubes
[M] so the Hat Brackets wrap around the Slide Tubes and
align with the holes located along the Wing [N] as shown.
Using two (2) 5/16in Carriage Bolts [Q], two (2) 5/16in
Carriage Washers [T], and two (2) 5/16in Nylock Nuts [U]
per Hat Bracket [P], connect the Hat Brackets to the Wing
[N]. [Fg. 8]
Hand tighten only at this time, further adjustment will
be required before final assembly.
A
Mounting Hole
[Fg. 8]
Page 3 of 19
A
K
M
Mounting Hole
N
Q
M
P
T
U
[Fg. 6]
[Fg. 7]
