Specifications
Nominal Output Voltage
Total Output Current
Output Connections
Universal AC Input Voltage
Input Frequency Range
AC Input Current
Typical Float Voltage (25°C)
Typical Absorption Voltage (25°C)
Reduced Output (battery temp 45°C to 49°C)
Battery Temperature Compensation Coefficient
ACR Continuous Rating
ACR Continuous Rating (during AC charging)
ACR Cranking Rating (30 sec.)
ACR Combine Voltage
ACR Open Voltage
ACR Manual Combine Timeout
Operating Current (no AC power)
Negative Terminal Stud Size
Maximum 1/4" Terminal Stud Torque
Positive Terminal Stud Size
Maximum 3/8" Terminal Stud Torque
Quick Connect Terminal Size
Operating Temperature Range
Storage Temperature Range
Warranty
Battery Types
Battery Number of Cells
Recommended Maximum Battery Capacity
Recommended Minimum Battery Capacity
Regulatory
Designed and constructed for compliance to UL-1236 Marine, CSA 22.2 No. 107.2 and ABYC A-31 standards.
Ignition protected per ISO 8846 and SAE J1171. Meets FCC Part 15, Class B requirements. Designed and tested
to comply with California Energy Commission (CEC) efficiency standards.
Waterproof IP67 - protected against immersion up to 1 meter for 30 minutes
4600 Ryzex Way
Bellingham, WA 98226 USA
p 360.738.8230
f 360.734.4195
conductor@bluesea.com
www.bluesea.com
11
12V DC
20A DC
2 positive, 1 negative
100V-240V AC
50/60 Hz
4.0A @ 100V
1.8A @ 200V
13.5V DC
14.4V DC
4A DC / Limited to Float Voltage
-30 mV/°C (maximum offset ±0.88V)
170A
80A
300A
13.0V (2 min.)
13.5V (30 sec.)
12.75V (10 sec.)
12.35V if voltage is rising
10 minutes
10mA
1/4"-20 (accepts M6 ring terminal)
60 in-lb (6.8 Nm)
3/8"-16 (accepts M10 ring terminal)
140 in-lb (15.8 Nm)
1/4" x 0.032"
-20°C to 49°C
-30°C to 80°C
5 Year
Flooded, AGM, TPPL
6 cells
400Ah (20h rate), Total of both banks
100Ah (20h rate), Per bank
Specifications are subject to change. See bluesea.com/products/7608 for current information.
