2.0

General product description, features and optional functions

2.1 Product description
The MultiControl Duo pump control system is used to control the levels of fluids.
The fill level is determined by means of the ram pressure, air bubbles, an external sensor (4 - 20 mA) or float
switch, as required. The motor contactors actuate two pumps with a maximum power of 4 kW (optional to 5.5
kW) directly. 5 relay contacts are also available for issuing fault messages.
Operation and adjustment are extremely easy. Switch points, times and motor current limitation are set with a
digital potentiometer. All values can be retrieved on the LCD display.
LEDs indicate operating statuses and fault messages. Buttons for the manual - 0 - automatic functions are
also available.
2.2 Features
- LCD plain text display
- Manual - 0 - automatic functions
- Acknowledge button
- Forced activation of the pump
- Internal acoustic alarm
- Floating overflow alarm
- Operating hours counter
- Pump change
- High stability
- ATEX mode
- Recording of level by means of an internal pressure transducer, an external probe (4 - 20 mA) or float switch,
as required
- Connection to control systems via digital and analogue inputs and outputs
- All settings and fault messages are retained after a power failure
- Rotating field and phase failure monitoring (to be activated via the menu)
- Measuring range of 0 - 12.50 m can be selected for the external 4 - 20 mA level probe via the menu
- In manual mode, the pumps switch off automatically after a runtime of 2 minutes.
NEW to the scope of delivery!
NEW!
- Input for float switch for protection against dry running
- Analogue outputs for 0-10 V and 4-20 mA
- Fault memory
- Runtime monitoring
2.3 Optional functions and components
(Only included in the scope of delivery if specifically listed on the PO)
- External locking instead of protection against dry running
- Interpump delay can be set via the menu (staggered activation of the pumps)
- Maintenance note in the display
- Integrated main switch
- Integrated mechanical motor protection switch
- Additional pressure sensor for redundant overflow alarm with activation of the pumps
MultiControl Duo
- Thermal and electrical monitoring of the pumps
- Pump switch-off via tripping point and overrun
- Electronic monitoring of the motor current
- Variable staggered start-up (start delay)
- Floating and non-floating collective fault signal
- Storage of number of pump starts
- Ammeter
- Forced switchover
- Easy operation
- Service mode
