UPS SELFTEST
This function is only effective when UPS type setting is "HV". Therefore, please disconnect all
loads and utility first before executing this function. Then, please change UPS type to "HV".
For the detailed operation, please check "System Parameter" menu under Advance➔
Maintainer directory.
After changing UPS type to "HV", you have to restart the UPS. After the UPS is restarted,
please enter Advance screen and enter Maintainer password. It will show "UPS SELFTEST"
selection in the screen. In the screen, all tested items are shown "unknown". Simply click
"UPS SELFTEST" button, the UPS will start self-test. If the UPS is normal, it will show
"Normal" in all columns. Otherwise, "Unknown" will be displayed in the columns.
After the UPS self-test passes, the screen will be black automatically. If the UPS self-test is
abnormal, it will stop on the abnormal screen. At this time, the maintenance personnel should
repair the UPS according to the self-test instructions. Please check local dealer for self-test
instructions.
3-2-5. Information screen
Touch the icon to enter information page. Touch the icon or to browse
information. Touch the icon to return to main screen. Touch the icon to go back to
previous menu.
