Wiring Diagram
COK-E36/42/48CSX
COK-E36/42/48CBGX
BODY
22
REMOTE BLOWER CIRCUIT DIAGRAM
MOTOR
BLACK
WHITE
LED LED
REMARKS: CONDENSER 15 uF 370V AC120V 60Hz (CBE-1000)
CONDENSER*2 25uF 250V AC120V 60Hz (PBN-1000A)
VOLTS
120
BODY
GREEN
WHITE
BLACK
BLUE
RED
WHITE
WHITE
BLACK
B/W
LED LED
for 48" only
Okeanito Use, Care, and Installation Guide
HZ MAX AMPS
CBE-1000 6.2
60
PBN-1000A 5.1
WHITE
YELLOW
RED
BLUE
WHITE
L L
BLACK
Control PC
