Dynacode IP
Key:
Rotate layout
Key:
Alignment

Ribbon Save - Continuous Mode

Keys: , , ,
Mode
Mode: Standard
Transfer ribbon correction
Key:
Performance information
Key:
Expert parameters
Key:
Printhead down time
Ribbon motor early start
time
Key:
Minimal print speed
Print offset border
calculation
128
According to standard the layout is printed ahead with a rotation of 0°. If the function is
activated, the layout is rotated by 180° and printed in reading direction.
The adjustment of layout is effected only after 'flip/rotate layout', i.e. the adjustment is
independent of the functions flip and rotate.
Left: The layout is aligned at the left-most position of printhead.
Centre: The layout is aligned at central point of printhead.
Right: The layout is aligned at right-most position of printhead.
,
Selection of ribbon save mode.
Off: Ribbon save set to Off.
Standard: Maximum ribbon save performance, i.e. with this setting there is no loss of transfer
ribbon (apart from the safety distance of 1 mm, so the print fields are not printed one into the
other).
Shift: Layout data can be printed several times laterally displaced. A maximum utilization of
transfer ribbon can be achieved.
SaveStrt: No start signal loss, direct print module regulates the ribbon save quality
automatically according to requirement.
Speed: Determination of max. print speed.
On the base of this value all necessary calculations.
0 mm = It is always so far retracted that an optimal ribbon save is reached (no loss of transfer
ribbon).
Default: -1 mm
−xx mm = The feedback can be made smaller.
+xx mm = The feedback can be made larger.
sa/mm: The smallest possible distance of two prints with full ribbon save
cmin: Max. number of cycles per minute.
so/mm: Indicates the loss of ribbon save
Password protected menu
Enter password, press key
indicated.
PhDownT = printhead down time in ms:
Is used from ribbon save algorithm to use for the calculation of start time of printhead downward
movement.
REStartT = ribbon motor early start time in ms:
This value is added to the acceleration time of transfer ribbon movement. Time indication for the
time between 'motor reached material speed' and 'printhead burns'.
MinSpeed = minimal print speed:
If the min. print speed is increased, the max. number of cycles is also increased.
Calcoff = Turn On/Off print offset border calculation:
If this parameter is set to Off, then a smaller offset as the required print offset can be entered.
English
to confirm the entry and the following parameters are
