2.4 Weights and Dimensions

2.4.1 Module

H
(a)
(b)
Model
mm
1797
BAM10
1797
BAM20
2042
BAM30
2042
BAM40
2042
BAM50
2042
BAM70

2.4.2 Packaged Module

Model
mm
2039
BAM10
2039
BAM20
2284
BAM30
2284
BAM40
2284
BAM50
2284
BAM70
6
(c)
W
H W
ins mm ins mm
70.7 1260 49.6 1655
70.7 1260 49.6 1655
80.4 1260 49.6 1655
80.4 1260 49.6 1655
80.4 1260 49.6 1950
80.4 1260 49.6 1950
Dimensions
H W
ins mm ins mm
80.3 1418 55.8 1853
80.3 1418 55.8 1853
89.9 1418 55.8 1853
89.9 1418 55.8 1853
89.9 1418 55.8 2148
89.9 1418 55.8 2148
Module Dimensions
D (a)
ins mm ins mm
65.2 270 10.6 280
65.2 270 10.6 280
65.2 270 10.6 280
65.2 270 10.6 280
76.8 270 10.6 280
76.8 270 10.6 280
Weight
D
ins Kg lbs
73 853 1880.5
73 953 2101.0
73 1067 2352.3
73 1167 2572.8
84.6 1388 3060.0
84.6 1688 3721.4
(d)
D
(b) (c)
ins mm ins mm
11.0 850 33.5 880
11.0 850 33.5 880
11.0 850 33.5 880
11.0 850 33.5 880
11.0 850 33.5 880
11.0 850 33.5 880
H
W
Weight
(d)
ins Kg lbs
34.6 600 1322.8
34.6 700 1543.2
34.6 800 1763.7
34.6 900 1984.2
34.6 1100 2425.1
34.6 1400 3086.5
D
