Measuring sections for the Flowsensor FS109

15 Measuring sections for the Flowsensor FS109

15.1 Measuring sections with outer thread

Outer diameter
DA
["]
0,84
1,06
1,33
1,67
1,90
2,37
3,00

15.2 Measuring sections with flange connection

Outer Length
diameter LA
DA
["] ["]
3,50 52,36
4,50 59,06
5,50 80,71
6,63 96,46
16
Length Thread
LA
["] G ["]
13,78 1/2
16,93 3/4
20,87 1
25,98 1 1/4
29,53 1 1/2
36,61 2
46,06 2 1/2
Length DIN flange
L1 DN
["]
68,9 80
78,7 100
108,3 125
118,1 150
Tube wall Material
sickness
["]
0,10 steel 1.4301
0,10 steel 1.4301
0,13 steel 1.4301
0,13 steel 1.4301
0,09 steel 1.4301
0,14 steel 1.4301
0,14 steel 1.4301
DIN flange Tube wall
sickness
["] ["]
3,5 0,08
4,5 0,08
5,5 0,12
6,6 0,12
Overall length
["]
19,69
23,62
29,53
35,43
39,37
49,21
59,06
Material Overall
length
["]
steel 1.4301 19,69
steel 1.4301 23,62
steel 1.4301 29,53
steel 1.4301 35,43
FS 109
