RK Rose+Krieger SQZ-II Notice D'assemblage page 55

SQL linear unit
Version
SQL 40 × 40
SQL 40× 80
SQL 60
SQL 60 × 120
SQL 80 × 40
SQL 80
SQL 80 × 160
SQL 120 × 60
SQL 160 × 80
SQ-II/SQ-III linear unit
Version
SQ-II 30
SQ-II 40
SQ-II 40 × 80
SQ-II 60
SQ-II 60 × 120
SQ-II 80 × 40
SQ-III 80
SQ-II 80 ×160
Basic length in mm
250
250
250
250
300
300
300
350
400
Basic length in mm
148
178
178
240
236
260
260
256
6. Product information
Weight in kg
per 100 mm travel
basic length
3.61
4.00
4.18
5.07
4.63
5.94
7.50
5.07
7.50
Weight in kg
per 100 mm travel
basic length
1.3
2.1
2.4
5.6
7.7
6.9
7.3
8.9
Weight in kg
0.65
0.65
0.72
1.06
0.65
1.00
1.52
1.06
1.52
Weight in kg
0.15
0.22
0.39
0.50
0.90
0.57
0.77
1.39
55
