Fein WSG8-115 Serie Mode D'emploi page 24

en
24
Character Unit of measurement,
international
mm
mm
kg
L
dB
pA
L
dB
wA
L
dB
pCpeak
K...
m/s
m/s
h,AG
m/s
h,DS
m, s, kg, A, mm, V,
W, Hz, N, °C, dB,
min, m/s
For your safety.
Read all safety warnings and all
WARNING
instructions. Failure to follow the
warnings and instructions may result in electric shock,
fire and/or serious injury.
Save all warnings and instructions for future reference.
Do not use this power tool before you have
thoroughly read and completely understood this
Instruction Manual and the enclosed "General
Safety Instructions" (document number
3 41 30 054 06 1). The documents mentioned should
be kept for later use and enclosed with the power tool,
should it be passed on or sold.
Please also observe the relevant national industrial
safety regulations.
Intended use of the power tool:
Hand-guided angle grinder for dry grinding and cutting
of metal and stone in weather-protected environments
with the application tools and accessories recom-
mended by FEIN.
This power tool is also suitable for use with AC gener-
ators with sufficient power output that correspond to
the Standard ISO 8528, design type G2. This Standard
is particularly not complied with when the so-called dis-
tortion factor exceeds 10 %. When in doubt, please
refer to the generator instruction/specification guide.
Safety Warnings common for Grinding, Sanding,
Wire Brushing or Abrasive Cutting Off Operations
This power tool is intended to function as a grinder,
sander, wire brush or cut-off tool. Read all safety warn-
ings, instructions, illustrations and specifications pro-
vided with this power tool. Failure to follow all
instructions listed below may result in electric shock,
fire and/or serious injury.
Unit of measurement,
national
mm
mm
kg
dB
dB
dB
2
m/s
2
m/s
2
m/s
m, s, kg, A, mm, V,
W, Hz, N, °C, dB,
2
min, m/s
Explanation
Ø
M=Thread for clamping flange
l=Length of mounting thread
Weight according to EPTA-Procedure 01
Sound pressure level
Sound power level
Peak sound pressure level
Uncertainty
2
Vibrational emission value according to
EN 60745 (vector sum of three directions)
2
Mean vibrational value for angle grinding
2
Mean vibrational value for sanding with sand-
ing sheet
Basic and derived units of measurement from
the international system of units SI.
2
Operations such as polishing are not recommended to
be performed with this power tool. Operations for
which the power tool was not designed may create a
hazard and cause personal injury.
Do not use accessories which are not specifically
designed and recommended by the tool manufacturer.
Just because the accessory can be attached to your
power tool, it does not assure safe operation.
The rated speed of the accessory must be at least equal
to the maximum speed marked on the power tool.
Accessories running faster than their rated speed can
break and fly apart.
The outside diameter and the thickness of your acces-
sory must be within the capacity rating of your power
tool. Incorrectly sized accessories cannot be adequately
guarded or controlled.
Threaded mounting of accessories must match the
grinder spindle thread. For accessories mounted by
flanges, the arbour hole of the accessory must fit the
locating diameter of the flange. Accessories that do not
match the mounting hardware of the power tool will
run out of balance, vibrate excessively and may cause
loss of control.
Do not use a damaged accessory. Before each use
inspect the accessory such as abrasive wheels for chips
and cracks, backing pad for cracks, tear or excess
wear, wire brush for loose or cracked wires. If power
tool or accessory is dropped, inspect for damage or
install an undamaged accessory. After inspecting and
installing an accessory, position yourself and bystand-
ers away from the plane of the rotating accessory and
run the power tool at maximum no-load speed for one
minute. Damaged accessories will normally break apart
during this testtime.
=Max. sanding pad diameter
D
