Icon Icon name Description
Receiving display:
Receiving and Transmitting
Normal mode display
frequency; PMR and FRS Display current channel, Press the [▲]/[▼] button to select
mode display channels
Battery level indicator The more cells in the display, the more power the battery
Channel number indication 01-99
When "+" is displayed, it represents positive difference frequency;
Frequency offset direction
when "-" is displayed, it represents negative difference frequency. Do
not display for the same frequency transceiver.
VOX indication VOX has been turned on
Keypad lock indication Keypad lock has been turned on(PTT button are not restricted)
The signal intensity is displayed when receiving, the first five grids are
displayed when low power is transmitted, and the full grid is displayed
Field Strength
when high power is transmitted.
Ringtone 1-10 Category
LCD icon and Function Description
, Transmitting display:
03
Icon Icon name Description
Dual Standby
When "L" is displayed, it represents low power transmission of the
Low Power (Normal Mode) current channel; when is not displayed, it represents high power
transmission.
Narrow Band When "N" is displayed, it represents in the Narrow-band mode; when
(Normal Mode) is not displayed, it represents in the broad-band mode
CTCSS: 50 Group (Normal Mode) 38 Group (FRS/PMR)
CTCSS
DCS DCS: 104 Group (Normal Mode) 83 Group (FRS/PMR)
Brief of the Function
1. Output Power:
PMR446:0.5W
2. Frequency Range:
409(China) 467(TaiWan, China) 446(Europe) 442(USA) 447(Southeast Asia) 325(Philippines)
476-477(Australia) 433(Russia) 444(Norway) 448-447(Korea) 464(South Africa)
3. Channel: Up to 99 Channel (Preset according to different countries or regions)
