3.5 - SETTING THE TIME

• The unit provides the user with two operating program that can be set to start and stop at programmed
times. for example,you might want the unit to start shortly before returning home. to use these programs
the user must first set the time on the remote control, then set the time(s) for the program(s) to start.
3.5.1 - TIMER AND CLOCK SETTING (fig.E)
to set time, work with the remote control as follows:
a. Press the B6 button (Set timer) as many times as necessary to display the hour h at position (D10).
b. Set the hour with the B7 buttons (+ and -).
c. Press the B6 button as many times as necessary to display the minutes m at position (D10).
d. Set the minutes with the B7 buttons (+ and -).
e. Press the B6 button to save the time and proceed with the timer programming.
3.5.2 - TIMER AND CLOCK SETTING (fig.F)
to set time, work with the remote control as follows:
a. Press the B6 button (Set timer) as many times as necessary to display the hour h at position (D10).
b. Set the hour with the B7 buttons (+ and -) .
c. Press the B6 button as many times as necessary to display the minutes m at position (D10).
d. Set the minutes with the B7 buttons (+ and -).
e. Press the B6 button to save the time and proceed with the timer programming.
3.5.3 - TIMER SETTING (PROGR. 1 AND PROGR. 2) (fig.E1)
it is possible to set one or both the timer programs.
to set the times for starting and stopping the unit, proceed as follows:
a. Press once or more the B6 button (Set timer) until when symbol
gram).
b. Use the B7 buttons (+ and -) to increase or decrease the hour in which you wish the air conditioner
activates.
the hour variation settable with the B7 buttons (+ and -) is of 30 minutes.
c. Press the B6 button (Set timer) a second time; symbol
d. Use the B7 buttons (+ and -) to increase or decrease the hour in which you wish the air conditioner
switches off. the hour variation settable with the B7 buttons (+ and -) is of 30 minutes.
e. Press the B6 button (Set timer) again; symbol
f. Use the B7 buttons (+ and -) to increase or decrease the
hour in which you wish the air conditioner activates.
the hour variation settable with the B7 buttons (+ and -)
is of 30 minutes.
g. Press the B6 button (Set timer) again; symbol
(Stop time for the 2° program) .
h. Use the B7 buttons (+ and -) to increase or decrease the
hour in which you wish the air conditioner switches off.
the hour variation settable with the B7 buttons (+ and -)
is of 30 minutes.
i. to return to the normal operation mode, press once or more
the B6 button (Set timer) until when all the symbols
related to this setting on the display turn off.
USA - 20
(D8a) (Start time for the 1° pro-
(D8b) (Stop time for the 1° program).
(D9a) (Start time for the 2° program).
D8b
(D9b)
D8a
D9a
D9b
E1
