Type of receiver
Frequency response
THD distortion
S/N ratio
Modulation
Deviation
Conformity to Directive
Maximum capacity *
Net weight (with power supply)
*
This figure is indicative and capacity depends both from set up and place of use.
Capacity can be very much reduced if there are obstacles and metal and/or reinforced concrete structures.
8.

HEADPHONES (FIRE ONE)

The EME ONE system also includes a custom headphone from Beyerdynamic,"FIRE ONE".
These earpieces provide excellent sound quality throughout the audio band. They are equipped
with neodymium audio drivers and lightweight metal supports, providing versatility and excellent
quality.
The following items are supplied along with the earpieces:
-
3 spare rubber pieces (size S/M/L)
-
1 pair of "memory foam" – eartips
-
1 semi-rigid casing

8.1. Technical specification

Transducer type
Frequency response
Nominal impedance
Sensitivity
Cable length
Connector
SYSTEM
Monoantenna / 8 channels
from 40Hz to 16KHz ~ 3dB
<1% at nominal deviation
104dB "A" weighted
F3E (Frequency Modulation)
35KHz nom. @ 1KHz sinusoidal
1995/5/CE
40m (indoor)
100m (outdoor)
800gr
Dynamic
20 – 22,000 Hz
12Ohm
104dB
1,2m
mini stereo jack plug (3,5mm)
