revised 12/2017
DESCRIPTION
Base Assy .................................................................................................D-2 - D-3
Holding Tank Assy.....................................................................................D-4 - D-5
Vacuum Tank Assy ....................................................................................D-6 - D-7
Plumbing System ......................................................................................D-8 - D-9
Water Flow Diagram .............................................................................D-10 - D-11
* Use the part numbers from the "Ref. No." columns in this parts list. If the "Ref. No." column is blank; look
under the "Kit" column to identify which kit contains the part in question, then use the kit callout, for example
"K1", to fi nd the "Ref. No." for that kit.
* Specify the model number and serial number of the machine.
* Use the space below to record the model number and serial number for future reference.
Model No. ________________________ Serial No. _____________________________
9/2016
New & Reconditioned Equipment - www.southeasternequipment.net
TABLE OF CONTENTS
WHEN ORDERING PARTS
Kit Item Ref. No. Qty Description
K1 1 16 Washer Flat 3/16 Zinc Plat
K1 2 2 Screw-BHS-Brass-10-32x3/8-MS
K1 3 3 Washer EPDM 7/32 X 1/8
4 805 1 Chain-Cover
5 905 2 Caster Swivel 4 Gray Non MA
K1 6 2 Nut, Hex Nyl Loc 10-24
K1 7 3 Scr- Hex SS 1/4-20 X .75
K1 8 16 Scr, Hex Hd Loc 1/4-20 x .50
K1 9 3 Wsh, Flt SS .260 X 1.000 X .074
10 56113012 1 Solution Tank
11 56113034 2 Hinge Plate
K1 56113103 1 Kit-Hardware Solution Tank
PAGE
56042670 - MC1200
PARTS LIST
D-1
