1 GENERAL DESCRIPTION
The Motorsan macerator is designed to lift waste water in
individual homes where gravity drainage is not possible.
1.1. APPLICATION
Motorsan is a high-output sanitary macerator based on
the rotary grater principle. It is used to discharge effluents
from a toilet. It can also be used to pump waste water
from a washbasin, shower or bidet. It is designed for hou-
sehold use only. When correctly installed, Motorsan does
not require any particular maintenance.
ATTENTION: all applications other than those set out in
the present instructions are prohibited.
Motorsan provides a high level of performance and reliabi-
lity, as long as all the rules concerning installation and
maintenance set out in these instructions are complied
with carefully. In particular, the following instructions are
very important:
Failure to comply with these instructions may put
personal safety at risk,
Instructions warning of the presence of an electrical
hazard,
"ATTENTION" Failure to comply with these instructions may
lead to risks concerning operation of the equipment.

1.2. TECHNICAL DATA

Application 1 toilet + 1 hand basin + 1 shower + 1 bidet
Vertical discharge height 6 m
Voltage 230-240 V
Frequency 50 Hz
Maximum power input 500 W
Maximum current input ..................
Electric class I
Protection class IP44
Net weight ..................
2 LIST OF THE PARTS SUPPLIED: diagram 2
3 MEASUREMENTS AND OVERALL DIMENSIONS: diagram 3
4 PERFORMANCE GRAPHS: diagram 4
5 INSTALLATION
8
Motorsan
5.1. CONNECTING THE TOILET
Motorsan must be connected to a toilet with a horizontal
outlet in compliance with standards EN33 or EN37. The
unit must be located in the same room as the toilet and
any other sanitary fittings connected to it. The unit must
be easily accessible for inspection and maintenance.
ATTENTION: to ensure that your equipment operates cor-
rectly, it is essential to use a flushing system containing
at least 6 litres of water.
Fix the lugs (F) to the unit using the screws (G): diagram
5.1 a
To facilitate assembly of the toilet: diagram 5.1 b
- Fix the toilet outlet sleeve D in place using the plastic
clamp E
- Coat the end of the toilet with liquid soap
- Line the sleeve up with the toilet outlet
- Slide the sleeve D onto the toilet outlet.
Once the unit is in place, fix it to the floor using 2 screws
(not supplied).
5.2. CONNECTING OTHER SANITARY FITTINGS
- Connecting to the side inlets (shower, washbasin,
bidet): diagram 5.2:
To connect fittings to the side inlets of the tank:
- Place the Ø 40 PVC tube in the nut L with its conical seal
J, and tighten the nut on the fitting.
Close off any unused inlets using the plugs - diagram 5.2:
- Insert the conical seal J on the plug K, taking care to
ensure that it is fitted the right way round (the thickest
part of the seal must be in contact with the seat of the
plug)
- Insert the plug with its conical seal in the nut L, making
sure that the plug is set flat on the seat of the nut
- Screw the assembly on the side inlets of the tank, tightly
enough to compress the seal correctly.
ATTENTION: to connect a shower, make sure that the bottom
of the shower tray is at least 13 cm above the floor level.
All sanitary fittings connected to a macerator must be fully
watertight. Even a small leak leads to unnecessary mace-
rator operation cycles.
5.3. CONNECTING TO THE DRAINS: diagram 5.3
The drain tube diameter must be 32 mm.
To connect the unit to the drain, use the pre-assembled
elbow / check valve fitting A, which can be oriented in the
desired direction. Then fix the assembly in place on the
unit's discharge tube, using the clamps B and C.
The drain from the unit must be connected to the mains
drainage pipes using a commercially available fitting.
Advice
It is preferable to fit the initial section of the drainpipe
vertically.
The horizontal piping must be installed with a drop of 1%.
It is advisable to fit a bleeder on the lower section of the
vertical pipe to drain the pipe if maintenance work has to
be carried out on the drain.
ATTENTION: Each elbow fitted on the unit drain results in
a reduction in the discharge height of about 50 cm per
elbow.

5.4. ELECTRICAL INSTALLATION:

FINISH ALL THE INSTALLATION WORK BEFORE CONNECTING
THE UNIT TO THE ELECTRICITY SUPPLY
The installation work must be carried out by a qualified
professional electrical engineer. The rules concerning elec-
trical installations in a bathroom, as set out in NF C15-
100, must be complied with.
The unit must be placed so that the power plug is accessi-
ble. The power circuit for the unit must be earthed (class I)
and protected by a highly sensitive differential circuit
breaker (30mA) set to at least 10A.
The electricity circuit must only be used to power the unit.
In case of doubt, arrange for the system to be inspected
by a qualified electrician.
If the power cable of the unit is damaged, it must be
replaced by the manufacturer or its After Sales Service to
avoid all hazards.
Protection of the motor: This unit is fitted with a thermal
protection system. To reset the safety switch if the unit
has overheated, disconnect the unit from the electricity
supply for two hours.
F
Notice d'installation
GB
Installation manual
6. PUTTING INTO SERVICE
Check that the installation work has been carried out cor-
rectly.
Connect the unit to the electricity supply.
Flush the toilet and check that the unit starts up and stops
correctly.
Check the tubes and fittings for leaks.
7. USE AND PRECAUTIONS
Toilets connected to a Motorsan are used in the same
way as ordinary toilets, and they require very little main-
tenance. Each time the unit is connected to the electricity
supply, it starts up for 5 seconds. The macerator starts up
automatically once the water in the tank reaches a certain
level.
All commercial or industrial uses are prohibited.
In the event of a long period of absence (holidays, etc.),
it is essential to turn off the mains water supply for the
house.
The unit does not require any particular maintenance. In
the event of a failure, all work on the unit must be carried
out by an approved repair specialist.
ATTENTION: The guarantee only covers evacuation of toi-
let paper, faeces and waste water. Any damage caused to
the unit by maceration of foreign bodies such as cotton,
tampons, sanitary towels, towelettes, foodstuffs,
condoms, or hair, or pumping liquids such as solvents or
oils is not covered by the guarantee.
8. SERVICING
To clean and descale the bowl of the toilet connected to
your macerator, use classic descaling products for sanitary
fittings.
To avoid build-up of scale inside the unit, it is advisable
to carry out a descaling procedure at regular intervals:
- Disconnect the macerator from the electricity supply,
- Pour a dose of descaling product into the bowl, diluted
in 3 or 4 litres of water,
- Leave to soak for several hours,
- Reconnect the macerator to the electricity supply
- Flush the toilet.
We recommend renewing the operation 2 or 3 times a
year.
