ESC ADVANCED SETUP
You can adjust certain parameters by using the SET button
located on the ESC's switch. To adjust the parameters, follow
the procedure below.
A. Switch on the ESC.
B. Press the SET button and release it when the green LED
starts flashing.
C. Use the SET button to cycle between the various
adjustable parameters. The number of green flashes
indicates the parameter, one flash = running mode, two
flashes = drag brake force and so on. The ESC will cycle
through all the adjustable parameters in a loop.
D. Once the green LED is flashing the number of times
relative to the parameter you wish to modify, press the
SET button until the red LED starts flashing, indicating the
current setting for that parameter, one flash = setting one,
two flashes = setting two, etc.
E. Press the SET button to change the current setting value,
the ESC will cycle through all the available settings.
F. Once the red LED is flashing the number of times relative
to the setting you wish to use, press the SET button for 3
seconds. The setting is saved.
G. Switch off the ESC to exit programming mode

ADJUSTABLE PARAMETERS

Running Mode
1) "Forward Only with Brake" this mode is meant for
competition use. In this mode the car can go forward and
brake, there is no reverse.
