1. Basics

1.3 Functions

1 Thermal insulation

Robust insulation shells with locking mechanism minimise the heat losses
while keeping the pump electronics cool. Can be (dis-)assembled for
installation on manifolds at a later stage. Smooth, uniform front hood for
easy cleaning and attractive appearance of various pump groups in the
heating system.
2 Ball valves
with thermometer. Integrated, adjustable backflow preventer in backflow
ball valve.
3 Mixer
As standard with bypass or with throttle plate as an accessory for exact
control of the supply temperature. Various actuators available (230V, 24V, etc.).
Actuator with integrated controller already installed with constant heat
regulation set.
12
1
2
3
