Digital ECOMETER · Operating and Installation Instruction
Subject to change without notice. Current versions and additional information can be found online
at www.bpw.de.
Function
A minicomputer that is protected from water and dirt counts the wheel revolutions using a magnet
and a reed contact.
The digital ECOMETER with threaded connection, special clasp locking ring and integrated ma-
gnet is available for all ECO
ECO Plus 2-axle units.
There is a sensed area behind the display disc which is indicated by the two protruding BPW
logos. The display is activated by bringing a metallic object (ferromagnetic) close to the area of the
logo.
Please note
The ECOMETER is not allowed to be installed, removed or set in a potentially
explosive atmosphere.
- The tyre rolling circumference is set initially before installation and cannot be changed subse-
quently.
- The ECOMETER is only allowed to be screwed on and off using torque-limited drivers (no im-
pact drivers!) or manually with a torque wrench.
- Caution! Do not bend the magnet with the spring during installation and removal.
- Please protect the reed contact in the cap against damage. Do not stack the caps one inside
the other, for example.
- The display is activated by bringing a metallic object (ferromagnetic) close to the sensed area of
the display (BPW logos).
- Renew the unit in case of damage to the housing, the battery compartment or battery cables,
the casting compound or other damage to the unit.
Plus
axles. The digital ECOMETER with bayonet lock is available for all
