Pin Assignments

Inputs Connector type Electrical properties
Power USB plug
USB 1.1 comm. USB plug
Patient response Jack, 6.3mm
stereo
Outputs:
Phones, Left/ Jack, 6.3mm
Right mono
Other electrical specifications:
Warble
5 Hz sine, ±5% modulation

Electromagnetic Compatibility (EMC)

See Appendix in English in the back of the manual.
AS608 - Instructions for Use - EN
5V
90Ω Impedance
Accepts both mono and stereo 6.3mm jack
Uses sleeve + tip or ring + tip for response. Tip 3.3V through 1KΩ.
Impedance total 6,75KΩ for stereo, 6,25KΩ for mono.
Voltage:
Up to 3V rms. by 10Ω load
Min. load
5Ω
impedance:
0,5Ω
Output
Uses sleeve + tip mono 6.3mm jack.
impedance:
Connection:
Page 28
