Brush or pad-holder installation
3. Insert the positioning pin (24, Fig. C) and deactivate the
transport/parking device (23b).
4. Lift the brush/pad cover (10, Fig. C) by prying the
handlebar (2).
5. Place the brush (12, Fig. I) or the pad-holder (13) under
the cover.
6. Lower the cover (10, Fig. C) by means of the handlebar
(2).
7. Connect the power supply cable (21, Fig. C) to the
electrical mains.
8. Hook the brush/pad-holder by pressing the brush/pad
switch (2, Fig. B) for a few seconds.
If the hooking operation is difficult, manually rotate the
brush/pad-holder counter-clockwise (Fig. J).
Adjustments
9. Using the knob (3, Fig. C), adjust the handlebar (2) to the
most comfortable position.

MACHINE START AND STOP

Machine start
1. Prepare the machine according to the procedure shown
in the previous paragraph.
2. Lower the squeegee (11, Fig. C) by means of the lever
(19).
3. Turn the solution flow control lever (4, Fig. C) to one of
the following positions, according to the type of cleaning
to be carried out:
– ECO system: When the lever (4) is in the "ECO"
position (5a), the machine works in a special
condition of programmed water "economy" usage; as
the water flow is set and constant, the machine can
work with a washing autonomy of 70-80 minutes
[0.08 gal/min (0.3 liters/min) average].
– Variable system: When the lever is turned to the left
(variable flow), it is possible to increase the capacity
up to 0.26 gal/min (1 liter/min).
During machine operation, it is not possible to close
completely the water flow to the brushes.
4. While keeping one hand on the handlebar (2, Fig. C),
start the machine by turning the brush/pad switch and
the vacuum switch (2 and 3, Fig. B) to "I".
Razor E17 — 909 6311 000(1)2006-01
INSTRUCTIONS FOR USE
Machine stop
5. Turn the brush/pad switch and the vacuum switch (2 and
3, Fig. B) to "0".
6. Disconnect the power supply cable from the electrical
mains.
7. Lift the squeegee by means of the lever (19, Fig. C).
8. Insert the positioning pin (24, Fig. C) and lift the
brush/pad by activating the transport/parking device
(23a).

MACHINE OPERATION

1. Start the machine according to the procedure shown in
the previous paragraph.
2. While keeping both hands on the handlebar (2, Fig. C),
move the machine and start scrubbing/drying the floor.
CAUTION!
To avoid damaging the floor surface:
– Do not use the brush/pad without the
solution.
– When the machine is stopped, stop the
brush/pad by pressing the switch (2, Fig.
B).
CAUTION!
Before lifting the brush/pad, stop its rotation
by pressing the switch (2, Fig. B).
3. If necessary, adjust the solution flow sent to the brushes
by turning the lever (4, Fig. C).
Machine speed adjustment
4. The machine speed depends on the floor type and on
the choice of using brush or pad.
If necessary, it is possible to adjust the machine speed
by following the relevant procedure in the Maintenance
chapter.
