INSTRUCTIONS FOR USE
SQUEEGEE BLADE CHECK AND
REPLACEMENT
1. Clean the squeegee (according to the procedure shown
in the previous paragraph).
2. Check that the edges of the front (5, Fig. E) and rear
blades (12) lay down on the same level, along all their
length; otherwise adjust their height according to the
following procedure:
– Remove the fixing springs (6) and adjust the front
blade (3) and the rear blade (4).
– Reinstall the fixing springs on the properly
adjusted front and rear blades.
3. Check the front blade (3, Fig. E) and the rear blade (4)
for integrity, cuts and tears; otherwise replace them
according to the following procedure. Check that the
front corner (9) of the rear blade is not worn; otherwise,
overturn the blade to replace the worn corner with the
other one (7), provided that it is not worn. If the other
corner is worn too, replace the blade according to the
following procedure:
– Remove the fixing springs (6) and replace (or
overturn) the rear blade (4).
– Reinstall the fixing springs on the properly
adjusted front and rear blades.
4. Reinstall the squeegee (11, Fig. C) and screw down the
handwheels (12).
5. Connect the vacuum hose (22, Fig. C) to the squeegee
(11).

BRUSH CLEANING

NOTE
It is advisable to use protective gloves when
cleaning the brush because there may be
cutting debris.
1. Remove the brush from the machine, according to the
procedure shown in the Use chapter.
2. Clean and wash the brush with water and detergent.
3. Check the brush bristles for integrity and wear; if
necessary, replace the brush.
10

TANK AND VACUUM GRID CLEANING

1. Drive the machine to the appointed disposal area.
2. Make sure that the power supply cable (21, Fig. C) is
disconnected from the electrical mains.
3. Lift the cover (1, Fig. I) and apply the cover stand (18,
Fig. I), then clean and wash the cover, the tanks (4 and
5) and the vacuum grid (6) with clean water.
Drain the water from the tanks by means of the drain
hose (16, Fig. C) and valve (18).
4. If necessary, release the retainers (2, Fig. F), open the
vacuum grid (1), remove the float (3), then carefully
clean and reinstall them.
5. Check the cover gasket (7, Fig. F) of the recovery water
tank for integrity.
NOTE
The gasket (7, Fig. F) creates vacuum in the
tank, which is necessary for vacuuming the
recovery water.
If necessary, replace the gasket (7) after removing it
from its housing (8).
When reassembling the new gasket, install the joint (9)
in the central area, as shown in the figure.
6. Check the gasket (7, Fig. F) bearing surface (10) for
integrity and sealing capabilities.
7. Check the compensation hole (28, Fig. C) for clogging.
NOTE
The hole (28, Fig. C) compensates the air in the
cover interspaces, thus allowing the creation
of vacuum in the recovery water tank.
8. Remove the cover stand (18, Fig. I) and close the
recovery water tank cover (1).
