INSTRUCTIONS FOR USE
Wiring diagram
(See Fig. K)
EV1: Water solenoid valve
FR:
Frame
M1:
Brush/pad motor
M2:
vacuum system motor
PL:
Plug
SW1: Brush/pad switch
SW2: Vacuum switch
Colour code:
BK:
Black
BU:
Blue
BN:
Brown
GN:
Green
GY:
Grey
OG:
Orange
PK:
Pink
RD:
Red
VT:
Violet
WH:
White
YE:
Yellow
ACCESSORIES/OPTIONS
In addition to the standard components, the machine can be
equipped with the following accessories/options, according
the machine specific use:
–
Brushes/pads of different materials.
For further information concerning the above-mentioned
optional accessories, contact an authorized Retailer.
6
USE
WARNING!
On some points of the machine there are some
adhesive plates indicating:
– DANGER
– WARNING
– CAUTION
– NOTE
While reading this Manual, the operator must pay particular
attention to the symbols shown on the plates.
Do not cover these plates for any reason and immediately
replace them if damaged.
BEFORE START-UP
Squeegee installation
1.
Install the squeegee (11, Fig. C) and fix it by means of
the handwheels (12), then connect the vacuum hose
(22) to the squeegee.
Solution tank filling
2.
Fill the solution tank (5, Fig. I) with a solution suitable for
the work to be carried out.
Do not fill the solution tank completely, leave few inches
from the edge.
Always follow the dilution instructions on the label of the
chemical product used to create the solution.
The solution temperature must not exceed 104°F
(40°C).
CAUTION!
Use only low-foam and non-flammable liquid
detergents, intended for automatic scrubber
applications.
NOTE
Use either the brush (12, Fig. I) or the
pad-holder (13) according to the type of floor to
be cleaned.
Razor E17 — 909 6311 000(1)2006-01
