ZS Alloy Jammer
If fitting to the deck, install the jammers forward of the winch, close enough for easy operation
of the handle and latch, ensuring enough space is left behind the product for removal of the jaw
This helps spread the load into lightweight composite decks or masts.
They are a tight fit to ensure good thread engagement. Drilling templates for deck layout are
provided with the product.
Warning : The studs should be screwed a maximum of 15mm into the body. Over tightening
may damage internal bearing surface
Side Mounting :
Replace the six body fasteners with longer bolts. These can be inserted from
maximum safe working loads are to be reached. Refer to specification chart (page 7).
Double check the hole pattern is correct for the jammer before drilling. The pattern is not
reversible.
Mast Mounting :
Mast mounting plates are available, see page 34 for details. CAD templates
can be download from:
www.spinlock.co.uk/cadlibrary
The Jammers are not designed to withstand high side loads. If the lead angle to the winch is greater
than 10 degrees, fit lead blocks or organisers aft of the jammers. Contact the Special Projects Team
Spinlock offer custom digital jaw surfaces for specific rope covers and ensure more consistent long
term holding
stretch material such as Technora or Vectran. The ceramic surface resists polishing and wear, allows
faster engagement onto loaded line and offers improved load holding.
16
www.spinlock.co.uk
spinlock_hi_load_A5_12_1.indd 16-17
If fitting to the deck, install the jammers forward of the winch, close enough for easy operation
of the handle and latch, ensuring enough space is left behind the product for removal of the jaw
staggered pattern. This helps spread the load into lightweight composite decks or masts.
Warning : The studs should be screwed a maximum of 15mm into the body. Over tightening
may damage internal bearing surface.
They are a tight fit to ensure good thread engagement. Drilling templates for deck layout are
provided with this product. Double check the hole pattern is correct for the jammer before
drilling. The pattern is not reversible.
Side mounting :
ZS1014B and ZS1618B Carbon Jammers are designed to be side bonded.
Mast Mounting :
Mast mounting plates are available, see page 34 for details. CAD templates
can be download from:
www.spinlock.co.uk/cadlibrary
Bonded Mounting :
ZS1014B and ZS1618B are designed for bonding directly onto decks,
spars and booms.
is essential to refer to your own engineering design data, load data and materials supplier for
guidance.
The Jammers are not designed to withstand high side loads. If the lead angle to the winch is greater
than 10 degrees, fit lead blocks or organisers aft of the jammers. Contact the Special Projects Team
Warning : Post installation cleaning is essential to avoid jaw set damage, slippage and
possible rope damage on first use. Lubricant is provided. Follow maintenace instructions
on page 22.
how to use
ZS Alloy / Carbon
pages 8-9
ZS Carbon Jammer

maintenance

spares
17
pages 22-23 pages 36-37
