chapter 7
b. Insert the SCSI module (C9939AC3) into the scanner.
c. Insert and tighten the two mounting screws.
3 Install the SCSI card into your computer (from the SCSI kit –
the instructions that came with the SCSI kit.
4 Connect the SCSI cable between the computer and the SCSI module.
5 Connect the power cord and adapter as shown in the following illustration.
6 Turn on the computer.
7 If other SCSI devices are installed on this SCSI card and the scanner does
not work, there might be a SCSI address conflict.
8 If there is a SCSI address conflict, change the scanner SCSI address.
Change the scanner SCSI address
If you have several SCSI devices attached to a single SCSI adapter card, each
SCSI device must have a unique SCSI ID. If the scanner does not work after
adding the scanner to a multi-device SCSI string, you might need to change the
SCSI address. To change the scanner SCSI ID (preset to 2), follow these steps:
1 Turn the computer off.
2 Ensure that the scanner is on.
3 Press the S
button (
SCSI Address: 2 should appear on the front panel display.
28
insert the SCSI module
tighten the two mounting screws
Power adapter cable
D
CAN OCUMENT
) on the scanner at the same time.
1
2
Power adapter
connect the power
T button ( ) and the E
O
) using
C6271
Power cord
T
DIT EXT
hp scanjet 8200 series
