25 Pump fuse
26 Power supply fuse
27 Power supply fuse
28 Fuse for heating resistor
29 2V fuse
ATTACHMENT 1 – DEINSTALLATION OF
ELECTRIC KIT
Necessary tools: Cross recess screwdriver (for
unscrewing the electric kit) Slotted screwdriver
or size 10 socket wrench (for loosening the
hose).
1 Unscrew the 4 cross recess
screws at the housing rim.
The 8 slotted screws cannot
be unscrewed.
2 Loosen the power cable out
of the cable slot.
3 Push the cable 50cm
into the inside of the
tank.
4 Push the hose of the
brush holder completely
into the tank.
5 Take the housing of
the electric kit out of the
degreasing bath.
6 Turn the electric kit by
90° to the left to let the
pump liquid drip off into
the tank.
7 Take the electric kit
out.
8 Place the electric kit
into the basin, loosen
the clamp at the pump
and pull the hose off.
9 Loosen the clamp with
a slotted screwdriver or
a size 10 wrench.
10 Take the hose of the
pump.
